SYNAPTIC PLUS Kabel instalacyjny wewnętrzny U/UTP CAT5E PVC 200MHz pudełko 305metrów Eca

SYNAPTIC and SYNAPTIC PLUS Installation Twisted Pair Cables

The SYNAPTIC and SYNAPTIC PLUS twisted pair installation cables are designed to create connections between multimedia signal distribution points and user connection outlets.

Product Details:

• Type: UTP (Unshielded Twisted Pair) cable, ideal for computer and telephone network installations, CCTV systems, etc., which are not exposed to electromagnetic interference.

Key Features:

• High Quality: Made from copper with an outer PVC sheath.
• Category: Exceeds Category 5e standards, tested up to 200 MHz bandwidth.
• Compliance: Meets the requirements of structured cabling standards ISO/IEC 11801, EN 50173, and EIA/TIA 568-B.2.

Specifications:

• Applications: For indoor use.
• Material: Copper cable with PVC outer sheath.
• Category Compliance: 5e UTP.
• Available Versions: Also available in 5e FTP, 6 UTP, and 6 FTP.
• Testing: Tested on a 90m length with a Fluke Networks DTX-1800 meter.
• Color: White.
• Packaging: 305m per package.
• Cable Construction: 4 pairs (4x2).
• Conductor: Copper wire [Cu].
• Conductor Diameter: 0.500 mm.
• Sheath Thickness: 0.500 mm.
• Conductor Insulation: HDPE, 0.88 mm.
• Outer Sheath Diameter: 5.00 mm PVC.
• Impedance: 100 Ω within the range of 1-200 MHz.
• Maximum Resistance: 9.5 Ω/100m within the range of 1-200 MHz.
• NVP (Nominal Velocity of Propagation): 69%.
• Delay Skew: ≤ 45 ns/100m.

These cables provide a reliable and high-quality solution for various networking needs, ensuring excellent performance and compliance with industry standards.
