SYNAPTIC Indoor Installation Cable U/UTP CAT5E PVC 305m box Eca

The SYNAPTIC and SYNAPTIC PLUS installation twisted pair cables have been specially designed for establishing connections between multimedia signal distribution points and user connection sockets.

UTP (Unshielded Twisted Pair) cables are well-suited for installations in computer networks, telephone systems, CCTV systems, etc., which are not exposed to electromagnetic interference.

The cable is characterized by high-quality construction - made of copper, with an outer PVC coating.

It meets the requirements of structural cabling standards such as ISO/IEC 11801, EN 50173, EIA/TIA 568-B.2.

Intended use: indoor.
Construction quality: copper conductors, PVC outer coating.
Meets category requirements: 5e UTP.
Also available in versions: 5e FTP, 6 UTP, and 6 FTP.
Tested: measurement conducted on a 90m section using a Fluke Networks DTX-1800 meter.
Color: white.
Quantity per package: 305m.
Cable construction: 4x2.
Conductor material: copper wire [Cu].
Conductor diameter: 0.500mm.
Coating thickness: 0.500mm.
Conductor insulation: HDPE 0.88mm.
Outer coating diameter: 5.00mm PVC.
Impedance within range: 1-100MHz: 100 Ω.
Maximum resistance within range: 1-100MHz: 9.5(Ω/100m).
NVP (Nominal Velocity of Propagation): 69%.
Propagation delay (ns/100m): ≤45.
