Huawei HG8245Q GPON ONT 4x GE, 2x POTS, 2x USB, WiFi AC Dual Band MIMO 3x3

Huawei EchoLife HG8245Q is an advanced optical network terminal (ONT) and a high-quality home gateway designed for FTTH solutions. Leveraging GPON technology, it provides households and small offices (SOHO) with access to ultra-broadband internet. The Huawei HG8245Q ONT features two POTS ports, gigabit Ethernet ports with automatic GE/FE adaptation, and dual-band Wi-Fi 802.11ac. The IEEE 802.11ac standard and 3x3 MIMO technology enable the device to operate on two frequencies - at 2.4 GHz with speeds up to 450 Mbit/s and at 5 GHz with speeds reaching 1300 Mbit/s. Advanced transmission features guarantee high-quality VoIP services, HD video streaming, and efficient internet use. The HG8245Q ONT from Huawei is equipped with a GPON port (SC/UPC type, class B+), and its tower-type standing enclosure allows for convenient device placement. The package also includes a power adapter with specifications of 12 V 3 A.

Key features of the GPON ONT HG8245Q:

• 4 gigabit Ethernet ports
• 1 RJ-11 telephone port (POTS)
• 2 USB ports
• Dual-band Wi-Fi - 2.4/5 GHz in AC standard
• 3x3 MIMO - up to 450 Mb/s in the 2.4 GHz band, up to 1300 Mb/s in the 5 GHz band
• Built-in antennas with a gain of 2 dBi

Specifications:

• 2 POTS ports
• 4 GE ports
• 2 USB 2.0 ports
• Dual-band Wi-Fi 2.4 GHz / 5 GHz
• IEEE 802.11 b/g/n (2.4 GHz)
• IEEE 802.11 a/n/ac (5 GHz)
• 3x3 MIMO
• Wavelengths: US 1310 nm, DS 1490 nm

GPON Port:

• Class B+
• Receiver sensitivity: -27 dBm
• Wavelengths: US 1310 nm, DS 1490 nm
• WBF (Wavelength Blocking Filter)
• Flexible mapping between GEM Port and TCONT
• GPON Authentication: compliant with G.984.3
• Bidirectional FEC (Forward Error Correction)
• SR-DBA (Single Rate Dynamic Bandwidth Allocation) and NSR-DBA (Non-Single Rate Dynamic Bandwidth Allocation)

Ethernet Port:

• Ethernet port-based VLAN tagging and tag removal
• VLAN transparent transmission: 1:1 VLAN, N:1 VLAN, or VLAN QinQ
• Limit on the number of learned MAC addresses
• MAC address learning

POTS Port:

• Maximum REN (Ringer Equivalence Number): 4
• Codecs: G.711A/μ, G.729a/b, G.722
• Fax modes: T.30/T.38/G.711
• DTMF (Dual-Tone Multi-Frequency)
• Emergency calls (with SIP protocol)

USB Port:

• USB 2.0
• Network-based on FTP (File Transfer Protocol)
• File/print sharing based on SAMBA
• DLNA DMS/UPnP AV (Digital Living Network Alliance Digital Media Server/Universal Plug and Play Audio-Visual)

WLAN:

• IEEE 802.11 b/g/n (2.4 GHz)
• IEEE 802.11 a/n/ac (5 GHz)
• 3x3 MIMO
• Antenna gain: 2 dBi
• WMM (Wi-Fi Multimedia)
• Multiple SSIDs (Service Set Identifiers)
• WPS (Wi-Fi Protected Setup)
• Concurrent operation at 2.4 GHz / 5 GHz

Power Supply:

• 11-14 V DC
• 3 A
