DCN Switch L2 PoE S4600-10P-P-SI 8x 10/100/1000 PoE+ (124W), 2x SFP

The DCN S4600-10P-P-SI is a Gigabit Layer 2 access switch equipped with 8 ports of 10/100/1000Base-T RJ45 with PoE+ support (124W) and 2 ports of 100/1000Base-X SFP. It is designed for telecommunications networks, ISPs, small business and enterprise installations, CCTV, and WiFi networks. The switch provides full support for multicast technology, a complete VLAN table, and advanced DHCP functionalities. With high throughput and a non-blocking switching matrix, it excels in high-performance operator networks.

Key Features:

• Interfaces: 8 x RJ45 PoE 802.3at/af 10/100/1000Mbps, Auto MDI/MDX and 2 x 1000Mbps SFP ports
• Class: Layer 2 access switch
• PoE Power Supply: 124W
• Switching Capacity: 20 Gb/s
• Throughput: 15 Mp/s
• Packet Buffer: 0.5 MB
• Jumbo Frames: 10K
• MAC Table: 8K
• Multicast MAC Table: 500
• ACL Table: 1.4K
• VLAN Interfaces (IP): 16
• Processor Clock Rate: 500 MHz
• Flash Memory: 32 MB
• RAM Memory: 128 MB

Additional Information:

• Shared MAC address table for unicast and multicast (1:1 ratio)

Enhanced Availability Features:

• IEEE 802.1D STP, 802.1w RSTP, 802.1s MSTP, IEEE 802.3ad LACP, Virtual Cable Testing, DDM, LLDP / LLDP-MED, Loop guard, ERPS (ITU-T G.8032)

Traffic Control:

• 802.1Q VLAN, Port-based VLAN, Protocol-based VLAN, IP subnet based VLAN, Voice VLAN, Mac VLAN, LACP, IP/MAC source/destination address algorithm (load balance), GVRP, 802.1ad VLAN Stacking (QinQ), Selective QinQ, Flexible QinQ

Security:

• Layer 2 MAC filtering, BPDU Tunnel, RADIUS and TACACS+ authentication and authorization, TACACS+ accounting/auditing, SSH v1/v2, DHCP/DHCPv6 snooping, IP/IPv6 Source Guard, Port security, IEEE 802.1x port-based / MAC-based

QoS:

• 802.1p - 8 priority queues per port, 802.1p queuing method, Trusted COS/TOS/IP Precedence/DSCP/Port number, Broadcast Storm Control, Rate Limiting, port-based, Strict priority, Weighted Round Robin, Weighted Deficit Round Robin, Strict priority in Weighted Round Robin

L2/L3 Multicast:

• Multicast VLAN, IGMP v1,v2, v3, IGMP Query, IGMP Snooping (v1,v2,v3), IGMP Snooping Fast Leave (v2,v3), IPv6 MLD v1/v2 Snooping

Layer 3 IPv6:

• IPv4/IPv6 Dual Protocol Stack, IPv6 address

Management:

• RS-232 Console Port (RJ45), GUI (Web), Telnet, SNMP v1/v2c/v3, TFTP/FTP, Configuration backup and restore, Multi-level CLI, DHCP Client/Relay/Server, DHCP relay per VLAN, DHCP options 43/60/82, DHCPv6 options 37/38, DHCPv6 Relay/Server, SNTP/NTP, Port Mirroring per IP/TCP/UDP, RSPAN, IEEE 802.3ah EFM, IEEE 802.1ag CFM

MIB:

• RFC1066 - TCP/IP‐based MIB, RFC1213, 1157 - SNMPv2c/v3 MIB, RFC1493 - bridge MIB, RFC2674 - bridge MIB extension, RFC1643 - ethernet MIB, RFC1757 - RMON group 1,2,3,9, RFC2925 - Remote Management MIB, RFC2233 ‐ SMIv2 MIB

Dimensions (W/D/H): 340x200x44 mm

Operating Temperature: 0 ºC ~ 50 ºC

Humidity: 10% - 90% (non-condensing)

Power Supply: 230V DC

Maximum Power Consumption: ≤150 W
