The Moxa ICF-1150-M-SC-IEX isolated converter, powered by 12 to 24 V DC, transforms RS-232/422/485 signals into multimode fiber optic signals. The manufacturer specifies the data transmission speed for the ICF-1150-M-SC-IEX converter ranging from 50 bps to 921.6 Kbps. Equipped with an SC fiber port, this model supports fiber optic cabling with specifications including 50/125; 62.5/125; 100/140 μm. The transmission distance for this model is 5 km, with a wavelength of 850 nm. Additionally, the Moxa ICF 1150 converter features an RS232 interface in the form of a female DB9 connector, and for RS485/422, a screw terminal. Moreover, this device is capable of operating in a ring typology. The ICF-1150-M-SC-IEX converter operates within a temperature range of 0 to +60 degrees Celsius.
Host Interface: RS-232
Output Interface: Fiber (ST)
Overload Protection of Stabilizer: Yes
Mounting Type: DIN Rail
Protection Against Electrostatic Discharge: 15 kV
Fiber Connector: ST
Transmission Distance (multi-mode): 5 km
Wavelength: 850 nm
RS-422 Connector Signals: RxD+,RxD-,SGND,TxD+,TxD-
RS-485 Connector Signals: RxD+,RxD-,SGND,TxD+,TxD-
Receiver Sensitivity: -20 dB
TX Output: -5 dB
Transmission Speed: 921.6 Kbit/s
Operating Conditions
Temperature Range (Operation): 0 - 60 °C
Relative Humidity Range: 5 - 95%
Weight and Dimensions
Product Dimensions (WxDxH): 30.3 x 70 x 115 mm
Power
Voltage: 12 - 48 V
Power Consumption: 163 mA
Certifications
Certifications: UL, CE, FCC, ATEX, UL/cUL
Indication
LED Indicators: Yes
